Using Business Template for the First Time



Questetra has published more than 50 Business-flows with the detailed descriptions. You will be able to utilize a highly advanced Workflow system easily by downloading and importing these Business Templates.

• 1. Get a Sample
• 2. Import
• 3. Modify
• 4. Release
• 5. Summary

If you do not have a login ID, apply here.

We recommend that you visit Get Started first if you are new to Questetra.

1. Get a Sample

Download an Archive from the Sample site or Business Apps collection

1-1. Find the Desired Business App

There are lots of Business Processes published on the Business Template page

Business Apps



1-2. Download a Business App Template

Download the required Business App Template

2. Import

Import a Business App Template as a Workflow App to Questetra

2-1. New Model from Archive

Select [App Settings] from the menu in the top-right of the screen to display a list of Apps.



Click on the [New App from Archive] button to display the the file selection screen



After selecting the file, click on the [Import] button to move to the properties editing screen

2-2. Setting App Properties and Organization Associations

Configure with the Organizations in your system and modify the properties if necessary, then click on the [Add new app] button

• In the Apps published on the Questetra Support site, the Organizational settings are tailored to a dummy company
  • Import cannot be continued if the configured dummy target Organization ID or Role does not exist in your workflow platform
    • Click on the "App List" on the left menu to leave the Import screen
    • After setting up the necessary Organization/Role, try again
• Some Apps will contain errors after being imported
  • The App cannot be run with an error
  • Set up the OAuth2 settings, HTTP communication connection destination, etc. in edit mode to eliminate the error

• Settings Required When Importing an Archive

3. Modify

Try to Modify the Workflow App to fit your needs

3-1. Begin editing the App

You will be able to edit the Flow by clicking on the [Edit] button

Please see the "Your first step in Questetra" and "M2. Defining Business Process" pages for how to edit a Workflow App

• Your first step in Questetra BPM Suite / Chpt.2: Creating a Simple App
• M2. Defining Business Process

4. Release

Release the imported Workflow App as a Workflow system

4-1. Release as a Workflow system

Click on the [Release developing Version] button

• Before "Release" and start operation, make sure that the behavior and screen display are as intended.
  • How to Ensure Apps Operate Correctly



It is now usable as a Workflow system, and the release date and time is recorded as the "Latest version" Please see the "Your first step in Questetra" and "M1. Handling Issues" pages for how to flow Business data and handle Issues

• Your first step in Questetra BPM Suite / Chpt.1: Using the Preinstalled App as a Workflow User
• M1. Handling Issues

5. Summary

Now, you have learned how to import and use the Business Templates published on the "Workflow Sample" page

You can also export Workflow Apps that you have created in Questetra as Business Templates (Archive / QAR files)
